Model No.︰EVVA 12V12
Brand Name︰EVVA
Country of Origin︰China
Unit Price︰-
Minimum Order︰1 pc
EVVA 12V12 12.8V 12V 13.2V 12.5Ah 165Wh for RV Electric Tools Deep Cycle LiFePO4 Battery Pack
Electrical Characteristics
| Cell | Lithium Werks ANR26650M1B / EVVA 26650/ EVVA 32700 |
| Nominal Voltage | 13.2V / 12.8V（4S5P module） |
| Nominal Capacity@0.2C | 12.5Ah |
| Power | 165 Wh |
| Internal Resistance (AC) | 50 mΩ |
| Cycel Life @ 1C 100% DOD | > 4000 Cycles |
| Max. Charge/Discharge Current | 30 A |
| Peak Discharge Current | 50 A (1S) |
| Monthly Self Discharge | Less than 2% |
| Charge Temperature | 0~60 ℃ |
| Discharge Temperature | -30℃ to 60 ℃ |
| Storage Temperature | -40℃ to 70 ℃ |
| Dimensions (L*W*H) | 180*77*170 +/- 2 mm |
| Weight | 2.11 +/- 0.05 Kg |
| Container | ABS+PC |
| Terminal | F2 |
| Applications |
UPS Systems / Telecom Backup Power / PV Solar-Storage / Off-grid Power / Electric Mobility / Medical Equipment |
If you have a desire to know more about this product, pls feel free to contact me. We can offer you a more detailed datasheet and a good price!
We support OEM service and sending you samples for testing!
Payment Terms︰ TT
